JF6025D24HBL-7B
JF6025D24HBL-7B from Jiefeng Electric. DC Axial Fans for electrical cabinets, automation equipment, power supplies, servers and ventilation cooling applications. OEM and…
Product overview
Product dimension drawing： Unit: mm Specification Table: Model Voltage Operating Voltage Range Current Power Speed Airflow Pressure Noise PART.NO. VDC VDC AMP Watt RPM M ³ /min CFM mmH2O InH2O dBA JF6025D05LBL 5 3.5～5.5 0.24 1.20 3000 0.44 15.60 2.92 0.12 26.0 JF6025D05HBL 5 3.5～5.5 0.72 3.60 5000 0.76 26.70 7.95 0.31 38.0 JF6025D12LBL 12 8.5～13.5 0.10 1.20 3000 0.44 15.60 2.92 0.12 26.0 JF6025D12MBL 12 8.5～13.5 0.20 2.40 4000 0.60 21.20 5.16 0.20 31.8 JF6025D12HBL 12 8.5～13.5 0.38 4.56 6000 0.90 31.80 11.15 0.44 42.2 JF6025D12HHBL 12 8.5～13.5 0.50 6.00 7500 1.12 39.50 16.84 0.66 49.5 JF6025D24LBL 24 18～26.5 0.05 1.20 3000 0.44 15.60 2.92 0.12 26.0 JF6025D24MBL 24 18～26.5 0.10 2.40 4000 0.60 21.20 5.16 0.20 31.8 JF6025D24HBL 24 18～26.5 0.19 4.56 6000 0.90 31.80 11.15 0.44 42.2 JF6025D24HHBL 24 18～26.5 0.25 6.00 7500 1.12 39.50 16.84 0.66 49.5 JF6025D48LBL 48 36～54 0.03 1.20 3000 0.44 15.60 2.92 0.12 26.0 JF6025D48MBL 48 36～54 0.05 2.40 4000 0.60 21.20 5.16 0.20 31.8 JF6025D48HBL 48 36～54 0.10 4.56 6000 0.90 31.80 11.15 0.44 42.2 JF6025D48HHBL 48 36～54 0.13 6.00 7500 1.12 39.50 16.84 0.66 49.5
Product specifications
- productType
- 直流轴流风机
- brand
- JIEFENGFAN
- housingType
- 普通塑胶框
- housingMaterial
- 塑料PBT+28%GF
- bladeMaterial
- 塑料 PBT+28%GF
- bladeCount
- 7
- overallSize
- 60.1*60.1*24.8 MM
- mountingSize
- 50.0*50.0 MM
- mountingHoleDiameter
- Φ4.3
- Ventilation Opening Size
- φ58.2 MM
- motorType
- 无刷电机
- insulationClass
- B级
- driveType
- 液压/含油/滚珠
- powerType
- 直流
- ratedVoltage
- 5V/12V/24V/48V
- ratedPower
- 1.2/6.0 W
- workingTemperature
- -30℃~+70℃
- workingHumidity
- 30%~70%RH
- speed
- 3000/7500 RPM
- airFlow
- 15.60/39.50 CFM
- airPressure
- 0.12/0.66 mmH₂O
- noiseLevel
- 49.5 dBA
- protectionGrade
- IP43
- lifeSpan
- 30000/50000 h
- weight
- 60.0 g
- wiringMethod
- 引线/端子
- safetyCertification
- CE/ROHS
- customFunction
- RD/FG/PWM/堵转/缓启
