JF4025D24HHL-5
JF4025D24HHL-5 from Jiefeng Electric. DC Axial Fans for electrical cabinets, automation equipment, power supplies, servers and ventilation cooling applications. OEM and …
Product overview
Product dimension drawing： Unit: mm Specification Table: Model Voltage Operating Voltage Range Current Power Speed Airflow Pressure Noise PART.NO. VDC VDC AMP Watt RPM M ³ /min CFM mmH2O InH2O dBA JF4028D12LBL 12 8.5～13.5 0.15 1.80 7000 0.25 8.73 6.07 0.24 36.6 JF4028D12MBL 12 8.5～13.5 0.23 2.76 8500 0.30 10.60 8.71 0.34 37.3 JF4028D12HBL 12 8.5～13.5 0.31 3.72 10000 0.36 12.60 12.04 0.47 41.1 JF4028D12HHBL 12 8.5～13.5 0.40 4.80 12000 0.42 15.00 16.84 0.66 47.3 JF4028D12VHBL 12 8.5～13.5 0.48 5.76 14000 0.51 17.90 22.73 0.90 50.9 JF4028D12SHBL 12 8.5～13.5 0.60 7.20 16000 0.58 20.40 29.62 1.17 52.6 JF4028D24LBL 24 18～26.5 0.08 1.80 7000 0.25 8.73 6.07 0.24 36.6 JF4028D24MBL 24 18～26.5 0.12 2.76 8500 0.30 10.60 8.71 0.34 37.3 JF4028D24HBL 24 18～26.5 0.16 3.72 10000 0.36 12.60 12.04 0.47 41.1 JF4028D24HHBL 24 18～26.5 0.20 4.80 12000 0.42 15.00 16.84 0.66 47.3 JF4028D24VHBL 24 18～26.5 0.24 5.76 14000 0.51 17.90 22.73 0.90 50.9 JF4028D24SHBL 24 18～26.5 0.30 7.20 16000 0.58 20.40 29.62 1.17 52.6
Product specifications
- productType
- 直流轴流风机
- brand
- JIEFENGFAN
- housingType
- 增压塑胶框
- housingMaterial
- 塑料PBT+28%GF
- bladeMaterial
- 塑料 PBT+28%GF
- bladeCount
- 5
- overallSize
- 40.0*40.0*27.6 MM
- mountingSize
- 32.0*32.0 MM
- mountingHoleDiameter
- Φ3.5
- Ventilation Opening Size
- φ38.0 MM
- motorType
- 无刷电机
- insulationClass
- B级
- driveType
- 液压/含油/滚珠
- powerType
- 直流
- ratedVoltage
- 12V/24V
- ratedPower
- 1.80/7.20 W
- workingTemperature
- -30℃~+70℃
- workingHumidity
- 30%~70%RH
- speed
- 7000/16000 RPM
- airFlow
- 8.73/20.4 CFM
- airPressure
- 0.24/1.17 mmH₂O
- noiseLevel
- 52.6 dBA
- protectionGrade
- IP43
- lifeSpan
- 30000/50000 h
- weight
- 38.0 g
- wiringMethod
- 引线/端子
- safetyCertification
- CE/ROHS
- customFunction
- RD/FG/PWM/堵转/缓启
