JF450-218B2HL
JF450-218B2HL from Jiefeng Electric. AC Centrifugal Fan for electrical cabinets, automation equipment, power supplies, servers and ventilation cooling applications. OEM …
Product overview
Product dimension drawing： Specification Table: Model Voltage VAC Freq Hz Current AMP Power Watt Speed RPM Capacitor Airflow Temperature Noise dBA Type V Hz A W RPM μF m³/cfm Min/Max ℃ dB(A) JF450-218B2ML(BMC) 220 50 1.3 260 930 10 3900/2294 -30/+60 60 220 60 1.6 350 1050 10 4200/2470 -30/+60 61 JF450-218B3ML(BMC) 380 50 1.0 300 920 / 3900/2294 -30/+60 60 380 60 1.2 360 1050 / 4200/2470 -30/+60 61 JF450-218B3HL(BMC) 380 50 1.0 550 1350 / 5800/3400 -30/+60 69 380 60 1.5 800 1450 / 6500/3825 -30/+60 74
Product specifications
- productType
- 离心风机
- brand
- JIEFENG FAN
- bladeMaterial
- 金属 Q235
- bladeDiameter
- 455MM
- overallSize
- 455*258MM
- mountingSize
- φ115MM
- mountingHoleDiameter
- 6MM
- motorType
- 异步外转子
- insulationClass
- H级
- driveType
- 滚珠
- powerType
- 交流
- ratedVoltage
- 110V，220V，380V
- capacitorModel
- 16μf
- ratedPower
- 260/800W
- workingTemperature
- -30℃~+70℃
- workingHumidity
- 30%~75%RH
- speed
- 920/1450RPM
- airFlow
- 3400/6500m³/cfm
- noiseLevel
- 60/74dBA
- lifeSpan
- 50000h
- weight
- 12000g
- wiringMethod
- 引线
- safetyCertification
- CE
