JF133-73B2HL
JF133-73B2HL from Jiefeng Electric. AC Centrifugal Fan for electrical cabinets, automation equipment, power supplies, servers and ventilation cooling applications. OEM a…
Product overview
Product dimension drawing： Specification Table: Model Voltage VAC Freq Hz Current AMP Power Watt Speed RPM Capacitor Airflow Temperature Noise dBA Type V Hz A W RPM μF m³/cfm Min/Max ℃ dB(A) JF133-73B2HL(FMC) 220 50 0.32 70 2300 2 290/170 -30/+60 61 220 60 0.40 85 2350 2 270/160 -30/+60 63
Product specifications
- productType
- 离心风机
- brand
- JIEFENG FAN
- bladeMaterial
- 金属 Q235
- bladeDiameter
- 133MM
- overallSize
- 133*99MM
- mountingSize
- φ58
- mountingHoleDiameter
- 4MM
- motorType
- 异步外转子
- insulationClass
- H级
- driveType
- 滚珠
- powerType
- 交流
- ratedVoltage
- 110V，220V，380V
- capacitorModel
- 2μf
- ratedPower
- 70/85W
- workingTemperature
- -30℃~+70℃
- workingHumidity
- 30%~75%RH
- speed
- 2300/2350RPM
- airFlow
- 160/290m³/cfm
- noiseLevel
- 61/63dBA
- lifeSpan
- 50000h
- weight
- 2000g
- wiringMethod
- 引线
- safetyCertification
- CE
