JF400-147B2HL
JF400-147B2HL from Jiefeng Electric. AC Centrifugal Fan for electrical cabinets, automation equipment, power supplies, servers and ventilation cooling applications. OEM …
Product overview
Product dimension drawing： Specification Table: Model Voltage VAC Freq Hz Current AMP Power Watt Speed RPM Capacitor Airflow Temperature Noise dBA Type V Hz A W RPM μF m³/cfm Min/Max ℃ dB(A) JF400-147B2HL(BMC) 220 50 1.20 260 1350 7 2850/1675 -30/+60 64 220 60 1.50 330 1450 7 2950/1735 -30/+60 68 JF400-147B3HL(BMC) 380 50 0.60 265 1380 / 2850/1675 -30/+60 64 380 60 0.75 320 1460 / 2950/1735 -30/+60 68 JF400-147B2ML(BMC) 220 50 0.72 135 940 6 2100/1235 -30/+60 56 220 60 0.85 155 1050 6 2250/1323 -30/+60 57
Product specifications
- productType
- 离心风机
- brand
- JIEFENG FAN
- bladeMaterial
- 金属 Q235
- bladeDiameter
- 404MM
- overallSize
- 404*175MM
- mountingSize
- φ90MM
- mountingHoleDiameter
- 6MM
- motorType
- 异步外转子
- insulationClass
- H级
- driveType
- 滚珠
- powerType
- 交流
- ratedVoltage
- 110V，220V，380V
- capacitorModel
- 10μf
- ratedPower
- 135/330W
- workingTemperature
- -30℃~+70℃
- workingHumidity
- 30%~75%RH
- speed
- 940/1450RPM
- airFlow
- 1235/2950m³/cfm
- noiseLevel
- 56/68dBA
- lifeSpan
- 50000h
- weight
- 8900g
- wiringMethod
- 引线
- safetyCertification
- CE
