JF250-100B2HL
JF250-100B2HL from Jiefeng Electric. AC Centrifugal Fan for electrical cabinets, automation equipment, power supplies, servers and ventilation cooling applications. OEM …
Product overview
Product dimension drawing： Specification Table: Model Voltage VAC Freq Hz Current AMP Power Watt Speed RPM Capacitor Airflow Temperature Noise dBA Type V Hz A W RPM μF m³/cfm Min/Max ℃ dB(A) JF250-100B2HL(BMC) 220 50 1.2 290 2650 6 1700/1000 -30/+60 76 JF250-100B3HL(BMC) 380 50 0.9 290 2800 / 1700/1000 -30/+60 77
Product specifications
- productType
- 离心风机
- brand
- JIEFENG FAN
- bladeMaterial
- 金属 Q235
- bladeDiameter
- 280MM
- overallSize
- 280*107MM
- mountingSize
- φ58MM
- mountingHoleDiameter
- 4MM
- motorType
- 异步外转子
- insulationClass
- H级
- driveType
- 滚珠
- powerType
- 交流
- ratedVoltage
- 110V，220V，380V
- capacitorModel
- 4μf
- ratedPower
- 290W
- workingTemperature
- -30℃~+70℃
- workingHumidity
- 30%~75%RH
- speed
- 2650/2800RPM
- airFlow
- 1000/1700m³/cfm
- noiseLevel
- 76/77dBA
- lifeSpan
- 50000h
- weight
- 4000g
- wiringMethod
- 引线
- safetyCertification
- CE
