YWFH2E-190-063M-BA
YWFH2E-190-063M-BA from Jiefeng Electric. AC Centrifugal Fan for electrical cabinets, automation equipment, power supplies, servers and ventilation cooling applications.…
Product overview
Product dimension drawing: Unit: mm Specification Table: Model Voltage Freq Current Power Speed Capacitor Airflow Temperature Noise PART NO. V Hz A W RPM μF M³/min CFM Min/Max ℃ dB(A) YWFH2E-190-063M-BA 220 50 0.27 60 2500 2.0 8.98 317 -30/+60 65 220 60 0.35 76 2700 2.0 9.91 350 -30/+60 68
Product specifications
- productType
- 离心风机
- brand
- JIEFENGFAN
- bladeMaterial
- 钢板DC01/Q195
- bladeDiameter
- φ190.0 MM
- overallSize
- φ190.0*71.0 MM
- mountingSize
- φ58.0 MM
- mountingHoleDiameter
- M4.0|深度5.0
- Ventilation Opening Size
- φ133.0 MM
- motorType
- 感应异步外转子电机
- insulationClass
- F级
- driveType
- 滚珠
- powerType
- 交流
- ratedVoltage
- 110V/220V/380V
- capacitorModel
- 2 µF
- ratedPower
- 60/76 W
- workingTemperature
- -30℃~+60℃
- workingHumidity
- 30%~70%RH
- speed
- 2500/2700 RPM
- airFlow
- 317/350 CFM
- airPressure
- 0.9/1.38 inch-H₂O
- noiseLevel
- 68 dBA
- protectionGrade
- IP44
- lifeSpan
- 40000 h
- weight
- 2.0 kg
- wiringMethod
- 引线/端子
- safetyCertification
- CE/ROHS
- customFunction
- 双电压 速度可调
